KAWASAKI, Japan--(BUSINESS WIRE)--Toshiba Electronic Devices & Storage Corporation (“Toshiba”) has launched the "TRSxxx65H series,” the company’s third and latest^[1] generation of silicon carbide (SiC) Schottky barrier diodes (SBDs) for industrial equipment. Volume shipments of the first 12 products, all 650V, start today, with seven products housed in TO-220-2L packages and five in DFN8×8 packages.

The new products use a new metal in a third generation SiC SBD chip that optimizes the junction barrier Schottky (JBS) structure^[2] of the second generation products. They achieve industry-leading^[3] low forward voltage of 1.2V (Typ.), 17% lower than the 1.45V (Typ.) of the previous generation. They also improve the trade-offs between forward voltage and total capacitive charge, and between forward voltage and reverse current, which reduces power dissipation and contributes to high efficiency of equipment.

Notes:

[1] As of July 2023.

[2] JBS structure lowers the electric field at the Schottky interface and reduces leakage current.

[3] As of July 2023, Toshiba survey.

Applications

• Switching power supplies
• EV charging stations
• Photovoltaic inverters

Features

• Industry-leading^[3] low forward voltage: V_F＝1.2V (Typ.) (I_F=I_F(DC))
• Low reverse current:

  TRS6E65H I_R＝1.1μA (Typ.) (V_R=650V)
• Low total capacitive charge:

  TRS6E65H Q_C＝17nC (Typ.) (V_R=400V, f=1MHz)

Main Specifications

Follow the links below for more on the new product.

TRS2E65H
TRS3E65H
TRS4E65H
TRS6E65H
TRS8E65H
TRS10E65H
TRS12E65H
TRS4V65H
TRS6V65H
TRS8V65H
TRS10V65H
TRS12V65H

Follow the link below for more on Toshiba’s SiC Schottky Barrier Diodes.

SiC Schottky Barrier Diodes

To check availability of the new products at online distributors, visit:

TRS2E65H

Buy Online

TRS3E65H

Buy Online

TRS4E65H

Buy Online

TRS6E65H

Buy Online

TRS8E65H

Buy Online

TRS10E65H

Buy Online

TRS12E65H

Buy Online

TRS4V65H

Buy Online

TRS6V65H

Buy Online

TRS8V65H

Buy Online

TRS10V65H

Buy Online

TRS12V65H

Buy Online
